The 12V DC to 220V AC 100W Inverter Circuit is a compact inverter module designed to convert 12V DC battery power into approximately 220V AC output. It includes an onboard transformer and inverter circuitry, making it suitable for DIY backup power systems, battery projects, solar applications, and electronics experiments.

Features

• 12V DC input
• Approximately 220V AC output
• Up to 100W rated output*
• Integrated transformer
• Built-in oscillator and switching circuit
• Compact PCB design
• Suitable for DIY inverter projects
• Designed for battery-powered applications

Specifications

*Actual output voltage, waveform, frequency, maximum continuous power, and input current depend on the specific circuit version and load.

Connections

Applications

• DIY inverter projects
• Emergency backup power
• Battery-powered AC supply
• Solar energy projects
• Small electronic loads
• Educational electronics projects
• Power electronics experiments
• DIY portable power systems

Advantages

• Compact design
• Integrated transformer
• Simple 12V DC input
• Provides high-voltage AC output
• Suitable for DIY projects
• Easy to integrate into a battery-powered system

Package Includes

• 1 × 12V DC to 220V AC 100W Inverter Circuit

⚠️ Safety Note: The output of this module can reach approximately 220V AC, which can cause serious injury or death. Use proper insulation, enclosure, fuse protection, wiring, and electrical clearances. Never connect the output directly to household mains wiring or a wall socket. The stated 100W rating should not be assumed to be a continuous rating unless confirmed by the specific manufacturer/module specifications.
